Frequency Range: VHF 136-174MHz; UHF 403-470MHz
Storage Channel: 255 Channels
Weight: 265g
Dimensions: 101.5 x 55.5 x 33.0mm
1. Features
The compact GP388, one of the market-leading radios in Motorola’s Professional Series, is an effective feature-packed communication solution for any organization. The compact radio offers broad functionality; an easy-to-use menu with full keypad for productivity, whilst security features protect users working alone or remotely.
With a wide range of accessories available within the Professional Series; it’s easy to build a tailored communications solution to meet your needs.
Signalling
• Private Line™
• 5-tone selective signalling
Adaptable and versatile
• Compact model for greater portability
• Easily programmed in the field to support additional features
• Ruggedised design and compelling user interface
Easy to use and set-up
• Programmable buttons for easy access to frequently used features
• Simple menus and alpha-numeric phonebook
Protecting users
• Emergency signalling
• Lone worker feature for staff working remotely
• Whisper mode for discreet communications
• Caller identification
Quality
• MIL Spec 810 compliant
• Meets IP54 environmental standards
• Passed Motorola Accelerated Life Test
• X-Pand™ voice compression technology
Efficiency
• Channel scanning • Call management features include call forwarding, escalating incoming call alert and missed calls list
Included as standard
• Battery • Antenna • Belt clip • Accessory dust cover • User manual
Accessory options
A wide range of accessory options are available to customise your radio
• Audio accessories • Batteries and chargers • Carry options
2. Specifications
Specifications |
|
GENERAL SPECIFICATIONS |
|
Channel Capacity |
255 |
Frequency |
136-174 MHz; 403-470MHz |
Dimension |
With Standard Li-lon battery 101.5 x 55.5 x 33.0 |
With High capacity Li-lon battery 101.5 x 55.5 x 38.0 |
|
Weight (gm) with: |
With Standard Li-lon battery 265 |
With High capacity Li-lon battery 285 |
|
Power Supply |
Rechargeable battery 7.5v |
Operating temperature: -20°C to +55°C |
|
Sealing |
Passes rain testing per IP54 |
Shock & Vibration |
Diecast with impact resistance polycarbonate housing, Meets MIL-STD810C/D/E/F |
Dust & Humidity |
Weather resistant housing Meets MIL-STD810C/D/E/F |
RECEIVER |
|
Frequency Stability |
<-119 dBm (0.25uV) |
Adjacent Channel Selectivity |
> 70dB (25kHz), >65dB (12.5kHz) |
Intermodulation |
>70dB |
Spurious Rejection |
>70dB |
Audio Distortion |
<5% |
Hum and Noise |
>40dB |
Conducted Emission |
< -57dBm for below 1GHz < -47dBm for above 1GHz |
Audio Output @ <5% Distortion |
500mW (at 24 ohm) |
TRANSMITTER |
|
UHF |
High Power 5W Low Power 1W |
VHF |
High Power 4W Low Power 1W |
Modulation Limiting |
≤ 5khz (25kHz) |
≤ 2.5khz (12.5kHz) |
|
Spurs and Harmonics |
9kHz - 1GHz < -36dBm > 1GHz < -30dBm |
Frequency Stability (-30°C to +60°C) |
+/- 2.5ppm |
FM Hum & Noise |
> 40dB |
Adjacent Channel Power |
-60 dB @ 12.5 kHz;-70 dB @ 20/25 kHz |
Audio Response |
+1, -3 dB |
Audio Distortion |
<5% |
