VHF UHF Motorola Digital Radio Vehicle-mounted Station Transceiver XiR M6660

Frequency Range: VHF 136-174MHz; UHF 403-470MHz
Storage Channel: 256 Channels
Dimensions: 44*1169*134MM
Weight: 1.3 kg


1. Features

MOTOTRBO XiR M6660 mobile radios are compact and capable for the busy mobile worker who needs digital technology at an affordable cost. You get all the advantages of digital – including integrated voice and data, twice the calling capacity and clearer voice communications.

The MOTOTRBO XiR M6660 has systems capability, so when you need the flexible coverage of IP Site Connect, the XiR M6660 can deliver.

XiR M6660 is the perfect fit for your analog system, too. With easy scalability and analog interoperability, you can move to digital at your own pace and budget. Transform your operation with digital voice and data communication.  XiR M6660 can help you achieve even greater productivity, safety and cost-efficiency.


•  Analogue / Digital

•  Voice Communications

•  Canned Text Message

•  Alphanumeric Display

•  Intelligent Audio

•  Dual Capacity Direct Mode

•  Voice Announcement

•  Digital Mobile Radio (DMR) Standards Compliant

•  IP54 Rated


•  Enhanced Privacy

•  Radio Management Suite

•  Over the Air Programming (OTAP)

•  Transmit Interrupt Capability

•  IP Site Connect

2. Specifications

General Specifications

 Frequency Range


Memory Channel


Channel Spacing

12.5/20/25 kHz

Power Output

1 - 25W; 25 - 45W

Power Supply

13.2Vdc (10.8 - 15.6 Vdc) Negative Vehicle ground

 Dimensions (L×W×H)

1.7 x 6.7 x 5.3 in (44 x 169 x 134 mm)


2,9 Ibs (1.3 kg)

 Communication Range

 about 10-20km




Meets MIL-STD 810-C,D&E and TIA/EIA 603

Transmitter Specifications

Channel Spacing

12.5 kHz / 25 kHz

Modulation Limiting

± 2.5 kHz @ 12.5 kHz / ± 5.0 kHz @ 25 kHz

FM Hum & Noise

-40 dB @ 12.5 kHz / -45 dB @ 25 kHz

Conducted/Radiated Emissions

-36 dBm < 1 GHz / -30 dBm > 1 GHz

Adjacent Channel Power

60 dB @ 12.5 kHz / 70 dB @ 25 kHz

Receiver Specifications

Frequency Stability

+/- 0.5ppm

Channel Spacing

12.5 kHz / 25 kHz


70 dB

adjacent Channel Selectivity (TIa603d)

50 dB @ 12.5 kHz

75 dB @ 20/25kHz

Audio Response

+ 1, -3dB

Digital Vocoder Type

AMBE +2™

Digital Protocol

ETSI TS 102 361-1, -2, -3
