Motorola Mobile Car Radio Transceiver With Vehicle Mounted GM360

  • Frequency Range: 136-174Mhz; 400-470Mhz
  • Storage Channel: 255
  • Dimensions: 186 x 180 x 59mm
  • Weight: 1450g
  • Description: A versatile solution for organizations with a mobile workforce, the easy-to-use GM360 offers a comprehensive set of features that can be easily customised to reflect the communications needs of a grow
  • INQUIRY   EMAIL

1. Features


The GM360, one of the market-leading radios in Motorola’s Professional Series, offers communications for the mobile workforce in larger organisations. The radio offers broad functionality; an easy-to-use menu with navigation keys for productivity and security features to protect users working alone or remotely.

Option boards and a wide range of accessories and portable radios are also available within the Professional Series. It is easy to build a tailored communications solution to meet your needs.


KEY FEATURES

Signalling

• Private LineTM

• 5-tone selective signalling

Easy to use and set-up

• Intuitive menu-driven user interface and large controls enable easy access to many features • 14 character alpha-numeric display

• Programmable buttons

• PC programmable*

Adaptable and versatile

• Option board capability allows additional features and customer-specific functions*

• Easily programmed in the field to support additional features

• Data capability allows interface to third party terminals to enhance communications

Protecting users

• Emergency signalling

• Lone worker

• External alarm

Quality

• MIL Spec 810 compliant

• Meets IP54 environmental standards

• Passed Motorola Accelerated Life Test

• X-Pand TM voice compression technology

Efficiency

• Channel scanning

• Call forwarding

• Status calls

• Car radio mute

• Memory channel

• Voice operated transmit (VOX)

Included as standard

• Battery power cable

• Enchanced compact microphone

• 3 point mounting tray

Accessory options

A wide range of accessory options are available to customise your radio • Microphones and desktop solutions • In-vehicle accessories • Mounting kits


2. Specifications

General Specifications

 Frequency Range

VHF:136MHz-174MHz
 UHF:403MHz-470MHz

Memory Channel

255 Channels

Channel Spacing

12.5/20/25 kHz

Power Output

1 - 25W; 25 - 45W

Power Supply

13.2Vdc (10.8 - 15.6 Vdc) Negative Vehicle ground

 Dimensions (L×W×H)

186 x 180 x 59mm (add 9mm for Volume knob)

 Weight

1450g

 Communication Range

 about 10-20km

Operation Mode

Intermittent

Sealing

Passes rain testing to IP54

Dust

Meets MIL-STD 810-C,D&E and TIA/EIA 603

Transmitter Specifications

Modulation Limiting

± 2.5kHz @12.5kHz; ± 4.0kHz @20kHz; ± 5.0kHz @25kHz

FM Hum & Noise

- 40dB @ 12.5kHz; - 45dB @ 20/25kHz

Conducted/Radiated Emissions

- 36dBm < 1 GHz; - 30dBm < 1 GHz

Adjacent Channel Power

- 60dBm @ 12.5kHz ; - 70dBm @ 20/25kHz

Receiver Specifications

Intermodulation (EIA)

78dB (VHF); 75Db(UHF)

Adjacent Channel Selectivity

- 40dB @ 12.5kHz; - 45dB @ 20/25kHz

Audio Response (300 to 3000Hz)

+ 1, 3dB
